Continuous Dryers

In continuous dryers, ambient air is used through the hot air production chamber to cool the grain.

‍

Specifications:

• A drying column comprising:
• 4 to 16 drying compartments (depending on the model and the chosen evaporation flow)
• 1 to 4 compartments are used for cooling (depending on the model and type of grain to be dried)

• A saturated air evacuation column

• 1 column for supplying hot air, insulated with double wall filled with glass wool

• 1 to 3 fans for extracting saturated air with vertical outlet, equipped with air flow regulation

• 1 ceiling with level detection system

• 1 2-phase burner, with modulating pulsed air type gas ramp

• A system for pre-ventilating the grain before drying

• A pneumatic grain extraction device, powered by a compressor

• 1 outdoor access by stairs with intermediate rest platform (depending on the model) and roof access platform

• A standard control panel, comprising:
• An automatic control and control of ventilation, burner, pneumatic extractor with regulation control proportional to grain flow, allowing uniform drying according to the input humidity, hot air safety, grain safety, grain level and control of the conveyors
• 1 digital dryer control and display screen with memorization of the different alarm parameters
• 1 output for printing

‍
